Dialyzer Reprocessing Unit

Price 4000 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Dialyzer Reprocessing Unit Specification

Measurement Range
0-9999 mL (fluid measurement)

Features
Digital control panel, Safety alarms, Pressure monitoring, Self-disinfection cycle, Built-in chemical dosing

Function
Dialyzer cleaning, disinfecting and performance verification

Display Type
Digital LCD

Instruments Type
Medical Equipment

Frequency
50 Hz

Usage Type
Hospital, Clinic

Storage Instructions
Store in dry, dust-free area

Accuracy
Within 3%

Equipment Type
Dialyzer Reprocessing Unit

Material
Stainless Steel & ABS Plastic

Condition
New

Technology
Microporous Membrane Cleaning

Portable
Yes (mobile wheels attached)

Wall Mounted
No

Real-Time Operation
Yes

Noise Level
Low (<50 dB)

Operating Type
Semi-Automatic

Use
Reprocessing dialysis dialyzers for reuse

Power Source
Electric

Power Consumption
120 W

Voltage
220 V AC, 50 Hz

Dimension (L*W*H)
400 x 450 x 1250 mm

Weight
45 kg

Color
White & Blue

Safety Lock
Yes

Number of Reprocessing Cycles
Up to 50 per hour

Automation Grade
Semi-Automatic

Pump Type
Peristaltic Pump

Water Pressure Range
0.15 0.3 Mpa

Microbiology Monitoring
Integrated Sample Ports

Chemical Container Capacity
2 L

Connection Type
Standard water and drain interface

Operating Environment Temperature
10C to 40C

About Dialyzer Reprocessing Unit

The Dialyzer Reprocessing Unit by Advin Health Care offers a reliable and automated solution for reprocessing dialyzers in hemodialysis centers. It performs multiple operations, including rinsing, cleaning, performance testing, and disinfection. With its microprocessor-based system, the unit ensures accuracy and repeatability for every cycle. Constructed from durable, medical-grade materials, it maintains sterility and protects against contamination. This unit not only enhances dialyzer reuse management but also minimizes waste and operating costs, making it ideal for modern dialysis facilities.

Advanced Features:

Fully automatic dialyzer reprocessing system
Microprocessor-based control with digital display
Integrated cleaning, rinsing, and disinfection cycles
Conductivity and pressure testing for quality assurance
User-friendly interface for simplified operation
Hygienic, medical-grade body construction
Reduces infection risk and contamination
Energy-efficient and cost-effective design
Consistent and reliable reprocessing performance
Suitable for all types of dialysis units and hospitals

Efficient Dialyzer Reprocessing

This unit supports up to 50 dialyzer reprocessing cycles every hour, enhancing workflow in hospitals and clinics. Featuring advanced microporous membrane cleaning technology, it ensures thorough cleansing and disinfection, meeting stringent hygiene standards. Its digital controls, integrated chemical dosing, and pressure monitoring optimize every step for safety and repeatability.

User-Friendly and Safe Operation

The semi-automatic operation, digital LCD display, and intuitive control panel make it straightforward to use, while safety locks, low-noise performance (<50 dB), and self-disinfection cycles add peace of mind. Real-time operation tracking, built-in microbiology sample ports, and safety alarms assure healthcare workers of maximum safety and efficiency during the reprocessing procedure.

Designed for Modern Healthcare Settings

With standard water/drain interfaces, a compact, portable footprint, and robust stainless steel with ABS construction, this unit fits easily into busy medical environments. Its 2L chemical container, accurate fluid measurement (within 3%), and minimal storage requirements make it scalable from small clinics to large hospitals.

FAQ's of Dialyzer Reprocessing Unit:

Q: How does the Dialyzer Reprocessing Unit ensure safe and effective cleaning of dialyzers?

A: The unit uses microporous membrane cleaning technology, automated peristaltic pumping, and integrated chemical dosing for thorough cleansing and disinfection. Real-time pressure monitoring, sample ports for microbiology checks, and built-in safety alarms further enhance operational safety and effectiveness.

Q: What is the typical process for reprocessing a dialyzer using this equipment?

A: The process involves connecting standard water and drain lines, loading the dialyzer, and selecting a cycle via the digital control panel. The machine automatically cleans, disinfects, and verifies the dialyzer's performance, allowing up to 50 cycles per hour. Sample ports facilitate routine microbiological testing throughout the process.

Q: When should dialyzer reprocessing cycles be performed, and how long does each cycle take?

A: Reprocessing should be conducted immediately after dialysis treatment or as per facility protocol. Each cycle is designed for quick turnaround, enabling up to 50 reprocessing cycles per hour, which helps maintain a steady supply of ready-to-use dialyzers in medical settings.

Q: Where can this reprocessing unit be installed and used effectively?

A: It is best suited for hospitals and clinics with dialysis facilities. The unit is portable with attached wheels and does not require wall mounting. Its compact size and standard water/drain interfaces make it easy to integrate into new or existing reprocessing rooms.

Q: What safety mechanisms are included to protect users and ensure reliable operation?

A: The unit features a safety lock, self-disinfection cycle, digital alarms for abnormal conditions, and real-time pressure monitoring. It also includes built-in sample ports for microbiology checks, ensuring that disinfection processes meet safety standards consistently.

Q: How should the Dialyzer Reprocessing Unit be stored when not in use?

A: For longevity and reliability, the unit should be stored in a dry, dust-free area as recommended. Regular self-disinfection and periodic maintenance checks help maintain optimal performance and hygiene.

Q: What are the main benefits of using this semi-automatic dialyzer reprocessing unit?

A: Key benefits include increased efficiency (up to 50 cycles/hour), enhanced safety through automated monitoring, reduced manual workload, reliable disinfection, portable and robust design, and suitability for both hospitals and clinics seeking to optimize dialyzer reuse safely.
